Green Data Center
In the fall of 2010, Syracuse University completed construction of the Syracuse University Green Data Center (GDC). Roughly half of the space in the GDC is hosted space designed to provide a secure physical environment that is flexible enough to allow access to the equipment by researchers and graduate assistants.
Over 120,000 linear feet—more than 22 miles—of wire was used in the construction of the electrical systems.
Almost one mile of piping is used in the heating and cooling systems.
Because the Green Data Center was constructed in accordance with LEED “Green Building” principles, more than 99 percent of all construction waste generated so far has been recycled. That’s over 1,200 tons (about 60 truckloads) of waste that did not go to a standard landfill.
More than 25,000 linear feet of electrical conduit, equivalent to about 83 football fields or 4.5 miles, has been used on the project.
About the Green Data Center (GDC)
In partnership with IBM and the New York State Energy Research and Development Authority (NYSERDA), 6,000 square feet of datacenter space was added that is powered by a unique tri-generation power plant which utilizes water chilled racks to increase power and cooling efficiencies. On site natural gas micro-turbines provide 650 kilowatts of power and their waste heat is used by two Thermax Absorption Chillers to provide equipment and building cooling. The GDC cooling capacity is approximately three times that needed by the data center; excess chilled water is used to provide air conditioning for adjacent campus buildings. Lead-acid batteries provide 17 minutes of emergency backup power (at full capacity) in the unlikely event that the turbines and the utility grid simultaneously fail. To help further research on green data center practices the GDC has been instrumented with hundreds of sensors.
It is now also the main center for production computing resources, marrying research and administrative computing interests.
[su_quote cite=”Syracuse University Campus Cyberinfrastructure Plan”]The internal GDC network is 10 Gigabit with redundant connections to all hosts and network components whenever possible. The GDC supports a robust virtual private cloud in which 95% of campus servers have been consolidated. This includes servers (both research and operational) on campus that were housed in poor environmental conditions within distributed locations.[/su_quote]
The GDC is connected to the campus network and the original data center via two bundles of geographically diverse, 144 strand fiber paths. This can be and has been used to provide direct connectivity between a researcher’s campus building and the hosted area in the GDC.
Green Data Center Hosting for Researchers
Roughly half of the space in the GDC is hosted space designed to provide a secure physical environment that is flexible enough to allow access to the equipment by researchers and graduate assistants. The hosted area is caged, and provides a separate entrance that allows access through a combination of ID cards, biometric finger prints, and PIN numbers. Over half of the computing load in the GDC serves research computing needs. Researchers on campus are able to rely on having space in the datacenter that is very low cost and provides ideal environmental conditions for their equipment with power redundancy from the multiple layers of protection including the traditional electric grid, natural gas fired turbines (with on-site propane gas storage), and UPS.
Disaster Recovery (DR)
Machinery Hall (MH), the older data center utilized prior to the construction of the GDC, has been repurposed into a DR site. Backup computing and storage capacity purposed for use in case of a disaster is currently available at the MH location. Anticipating that this computing capacity will typically be sitting idle, it is leveraged via a private virtual cloud for research computing. Researchers are able to use this capacity free of charge for their academic work.
